Item
Setting value
[Factory default]
Description
Setting Button - Displays the set contents as the custom dialog box.
Adjust the dialog box position. After adjusting, the adjusted con-
tents will be reflected to the dialog box position X, dialog posi-
tion Y, dialog width, and dialog height by clicking the Close on
the right end of the dialog title bar.
*1. The setting for scene 0 to 1023 is available when the number of maximum scenes has been changed.
Precautions for Correct Use
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
l
Individual Setting Region
Normal Dialog Box Setting Region
Item
Setting value
[Factory default]
Description
Dialog width 100 to 1920
[1024]
Sets the width of the dialog box.
Dialog height 100 to 1080
[768]
Sets the height of the dialog box.
Region Setting Dialog Box Setting Region
Item
Setting value
[Factory default]
Description
Setting target figure
No.
[0] Specifies the figure number for the unit to use for region setting.
The number that you can select depends on the unit that is
specified.
Position Setting Dialog Box Setting Region
Item
Setting value
[Factory default]
Description
Position X's data
No.
-1 to 999999999
[-1]
Specifies the data number on the X axis for the unit to use for
position setting.
Position Y's data
No.
-1 to 999999999
[-1]
Specifies the data number on the Y axis for the unit to use for
position setting.
Data reference but-
ton
- You can select the data number directly to enter it, or you can
enter it with the Data reference button.
Click the Data reference button to select the target data in the
Data reference dialog box.
Color Extract Dialog Box Setting Region
Item
Setting value
[Factory default]
Description
Color R's data No. -1 to 999999999
[-1]
Specifies the R’s data number for the color to specify for the
unit to use for color extraction.
Color G's data No. -1 to 999999999
[-1]
Specifies the G’s data number for the color to specify for the
unit to use for color extraction.
Color B's data No. -1 to 999999999
[-1]
Specifies the B’s data number for the color to specify for the unit
to use for color extraction.
8 Setting Windows
8 - 69
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-4 Editing contents are not reflected when you confirm the Sensor Controller after edit a layout by remote control
[Custom Dialog Tool]
8
8-4-2 Custom Dialog Tool
