5 Specify the destination folder and file name.

6 Click OK.

The dialog box showing transfer status is displayed, and the data is sent to the save destina-

tion.

9 Saving/Loading Data

9 - 9

FH/FHV Series Vision System User’s Manual (Z365-E1)

9-3 Saving Setting Data to the Controller RAMDisk or an External Storage Device
