Omron fh series User Manual

(example)
3 Click Update button.
4
Confirm dialog box is displayed.
After confirming the setting data, please click OK button. A template is updated.
Additional Information
When Update button is clicked after the template name is changed, it's possible to change the
template name.
l
Initialize a template
Describes the steps for creating a new template.
1 Click Initialize button.
2
Confirm dialog box is displayed.
9 Saving/Loading Data
9 - 25
FH/FHV Series Vision System User’s Manual (Z365-E1)
9-7 Backing up Sensor Controller Setting Data [Configuration Copy]
9
9-7-2 Backing up Sensor Controller Settings

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
