Term Definition
Operation mode
• Double Speed Multi-input:
A mode that processes the measurement flow for the first trigger and then proc-
esses the measurement flow in parallel for the second trigger to achieve a high-
speed trigger input interval. It is used together with the multi-input function.
• Multi-line Random-trigger:
A trigger mode that allows you to independently processing multiple measure-
ment flows.
With traditional image processing, two or more triggers cannot be acknowledged
at the same time. In Multi-line Random-trigger Mode, you can randomly input
multiple triggers into one Controller to independently process multiple scenes in
parallel.
• Non-stop adjustment mode:
A mode that allows you to adjust the flow and set parameters while performing
measurements.
The enables adjustments without stopping the line or stopping inspections.
• Standard:
A logging mode that allows complete parallel processing of measurements and
logging.
Traditionally, logging was not possible while processing measurements. Either
measurements or logging had to be given priority and the other one had to wait.
With this mode, you can save the measurement images in external storage with-
out affecting the transaction time.
Parallel processing (an
option for any of the
above operation modes)
Parallel processing splits part of the measurement flow into two or more tasks, and
processes each task in parallel to shorten the transaction time.
Processing items for parallel processing are used so that the user can specify the
required parallel processing.
Multi-input function A function that is used to consecutively and quickly input images.
It allows the next STEP signal to be acknowledged as soon as the image input
processing is completed. There is no need to wait for measurement processing to
be completed.
You can check whether image input processing has been completed with the status
of the READY signal. Even if the READY signal is ON when measurement proc-
essing is being executed, the next STEP signal can be acknowledged.
Terminology
39
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
