5 Specify the destination folder name and file type.
Item
Setting value
[Factory default]
Description
Folder name - Specify the destination folder name.
Format
• [Bitmap]
• Jpeg
Select the image format in which to save the im-
age.
Quality 0 to 100
[100]
Specify the quality of the Jpeg image to save.
6 Click OK.
The image is logged in the selected destination. If a file with the same name already exists in
the destination folder, the newly saved file overwrites the old one.
Additional Information
The save file name is the original file name and theextension.
9 Saving/Loading Data
9 - 48
FH/FHV Series Vision System User’s Manual (Z365-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
