Page #452 background imageLoading...
Page #452 background image
Functions Sensor Controller Remote operation PC
Layout change After the layout is switched, changes in
layout settings will be reflected in the
actual layout.
Changes are reflected immediately after
changing the layout settings. The layout
display does not match between the
Sensor Controller and the remote opera-
tion PC until the layout switching opera-
tion is performed on the sensor control-
ler.
Drive information The information of the drive that is con-
nected to the Sensor Controller is can
be checked.
Unavailable
Information display win-
dow
FZ_PanDA.Information-
Window
Available Its processing time is not displayed
when the Judgment display window
FZ_PanDA.JudgeWidow has been set
in non-display mode.
Precautions for Correct Use
The remote recovery dialog can be hidden behind a window of the non-stop adjustment mode
and the multi-line random trigger mode, both of which have two or more windows. To confirm
it, press Alt+Tab to switch between the windows.
The remote operation communications will be disconnected if a network setting (such as the
IP address, subnet mask, and default gateway) on the Sensor controller is modified using the
remote operation function. Launch Remote Operation Tool to establish the connection again.
The connection can fail immediately after a network setting has been changed. Please wait
for a while before reconnecting.
10 Advanced Usage
10 - 14
FH/FHV Series Vision System User’s Manual (Z365-E1)
