*5. Depending on the number of camera port of Sensor Controller.
*6. Enable only STEP 0 to 2.
*7. Enable only STEP 0.
*8. Enable only DSA 0 to 2.
*9. Enable only DSA 0.
*10. Disable to set. RS-422 is not supported.
*11.
Supported only the Sensor Controller with 2 ports: FH-££££-10, FH-££££-20
1 Overview
1 - 5
FH/FHV Series Vision System User’s Manual (Z365-E1)
1-1 Checking the System Config-
uration
1
1-1-2 Functional Comparison between the FH-series and FHV-series Controllers

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
