• In the measurement flow, you can change the processing to execute based on the inspection results
or input conditions of the vision inspection.
• You can use macro processing to execute pre-packaged processing items and functions in the FH
to create original programs. This allows you to create original measurement processes, display
processing, input and output processing, and settings dialog boxes that are custom-tailored to your
application.
2 Features
2 - 3
FH/FHV Series Vision System User’s Manual (Z365-E1)
2-1 Basic Mechanism for Measurements
2

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
