Output result
Processing item Identifier Processing item Identifier
Result output (I / O) OutputIO Result output (Message) OutputString
Data Output NormalData Parallel Data Output ParallelData
Parallel Judgement Out-
put
ParallelJudge Fieldbus Data Output FieldbusData
Result output (Parallel I /
O)
OutputParallelIo
l
Display result
Processing item Identifier Processing item Identifier
Result Display ResultDisplay Display Image File DisplayImageFile
Display Last NG Image DisplayLastNG Conveyor Panorama Dis-
play
ConveyorPanorama
Display image hold DisplayImage
Appendices
A - 53
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-15 List for Processing Item Identifier
A
