1-1
Smart Camera
First, please check to see if the package has all the necessary Smart Camera parts.
1-1-1
FHV7H-□□□□□-C Series
• Smart Camera
FHV7H-□□□□□-C: 1
• Connector cap for Ethernet cable (mounted on the body): 1
• Connector cap for an external lighting (mounted on the body): 1
• C mount cap (mounted on the body): 1
• C mount cover (mounted on the body): 1
• Instruction sheet: 1
• Membership registration: 1
• Compliance sheet: 1
1-1-2
FHV7H-□□□□□-S□□ Series
• Smart Camera
FHV7H-□□□□□-S□□: 1
• Connector cap for Ethernet cable (mounted on the body): 1
• Connector cap for an external lighting (mounted on the body): 1
• Special cover for FHV-LEM-S (mounted on the body): 1
• Instruction sheet: 1 each (Body, and lens module)
• Membership registration: 1
• Compliance sheet: 1
1 Confirm the Package
