3-5
Lighting Modules
3-5-1
Specifications
Model FHV-LTM-W FHV-LTM-R FHV-LTM-IR FHV-LTM-MC
Color White Red Infrared light Multi color
Peak wave length - Typ. 630 nm Typ. 850 nm R: Typ. 630 nm
G: Typ. 525 nm
B: Typ. 465 nm
IR: Typ. 850 nm
Light source LED LED LED LED
Risk group Group 2 Group 1 Group 1 R: Group 1
G: Group 2
B: Group 2
IR: Group 1
Usage environment
Ambient
temperature
range
Operating: 0 to +40℃, Storage: -25 to +65℃ (with no icing or condensation)
Ambient humidity
range
Operating & Storage: 35 to 85%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration tolerance Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration direction:
X/Y/Z, Sweep time: 8 minute/count, Sweep count: 10
Shock resistance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down, front/
behind, left/right)
Dimensions 52 mm × 91 mm × 77 mm (HxWxD)
Weight 270 g 270 g 270 g 270 g
Material Aluminum die-casting (ADC12), polycarbonate
Accessories
• Waterproof packing (small) FHV-XWP-CAM:1
• Waterproof packing (large) FHV-XWP-LTM: 1
• Light shielding sheet FHV-XLS-LTM: 1
• Lighting cover FHV-XCV: 1
• Hexagonal wrench (length: 60 mm): 1
• Instruction sheet: 1
• Compliance sheet: 1
3 Configuration
3 - 37
FHV Series Smart Camera Setup Manual (Z408-E1)
3-5 Lighting Modules
3
3-5-1 Specifications
To Next Page
