Smart Camera Models and System Configuration
l
Model Reference
FHV7H
-□□□□□-□□□-□□
①②③④⑤ ⑥
Model Refer-
ence
Meaning Description
① Imaging element type
• M: Monochrome
• C: Color
② Resolution
• 004: 0.4 [Mpix]
• 016: 1.6 [Mpix]
• 032: 3.2 [Mpix]
• 050: 5.0 [Mpix]
• 063: 6.3 [Mpix]
• 120: 12.0 [Mpix]
③ Shutter system
• Non: Global shutter
• R: Rolling shutter
④ Lens type
• C: C mount lens
• S: Autofocus lens
⑤ Focal length
• 06: 6 [mm]
• 09: 9 [mm]
• 12: 12 [mm]
• 16: 16 [mm]
• 25: 25 [mm]
⑥ Lighting color
• W: White
• R: Red
• IR: Infrared light
• MC: Multi color
2 Overview of FHV Series
2 - 5
FHV Series Smart Camera Setup Manual (Z408-E1)
2-1 Overview of System
2
2-1-1 Basic System of Measurement
