Optical Chart
l
Normal Lenses
(a) Smart camera: FHV7H-□004, FHV7H-□016 (for 3Z4S-LE SV-V series)
1,000
100
10
Camera placement distance (mm)
Y field of view (mm)
1 10 100 1,000
SV-10035V
SV-7527V
SV-5018V
SV-3518V
SV-2514V
5,000
3Z4S-LE
SV-1614V
SV-1214V
SV-0813V
SV-0614V
SV-04514V
SV-03514V
(b) Smart camera: FHV7H-□004, FHV7H-□016 (for 3Z4S-LE SV-H series)
1,000
100
10
Camera placement distance (mm)
Y field of view (mm)
1 10 100 1,000
SV-10028H
SV-7525H
SV-5014H
SV-3514H
SV-2514H
5,000
3Z4S-LE
SV-1614H
SV-1214H
SV-0814H
SV-0614H
3 Configuration
3 - 31
FHV Series Smart Camera Setup Manual (Z408-E1)
3-4 C Mount Lenses
3
3-4-2 Meaning of Optical Chart
To Next Page
