Command Control
206
FQ2-S/CH User’s Manual
for Communications Settings
File Save Commands
*: Commands that are used for the no protocol (TCP) communications only.
OK: Applicable command, RST: Command with restricted execution, NA: Non-applicable command
Function Parallel
p. 46, p. 75
PLC link
p. 136
EtherNet/
IP
p. 113
PROFINET
p. 160
No-proto-
col (TCP/
UDP/RS-
232C)
p. 181, p. 186
No-proto-
col (FINS)
p. 193
Saves scene data to the SD card inserted in the Touch
Finder as a file.
NA OK OK OK OK OK
Saves all scene data as a file to the SD card inserted in
the Touch Finder.
NA OK OK OK OK OK
Saves system data as a file to the SD card inserted in
the Touch Finder.
NA OK OK OK OK OK
Saves image data saved in the Sensor’s memory by the
logging function to the SD card inserted in the Touch
Finder as ifz data.
NA OK OK OK OK OK
Saves all image data saved in the Sensor’s memory by
the logging function to the SD card inserted in the
Touch Finder as ifz data.
NA OK OK OK OK OK
Saves the latest input image to the SD card inserted in
the Touch Finder as ifz data.
NA OK OK OK OK OK
Saves measurement data saved in the Sensor’s mem-
ory by the logging function to the SD card inserted in
the Touch Finder as csv data.
NA OK OK OK OK OK
Saves statistical data saved in the Sensor’s memory by
the logging function to the SD card inserted in the
Touch Finder as csv data.
NA OK OK OK OK OK
Saves all setting data (all scene data, system data, cali-
bration group data) for the Sensor to the SD card
inserted in the Touch Finder as a backup file.
NA OK OK OK OK OK
Saves the data for the specified calibration number as a
file to the SD card inserted in the Touch Finder.
NA OK OK OK OK OK
Saves all calibration data as a file to the SD card
inserted in the Touch Finder.
NA OK OK OK OK OK
Saves the specified number of model dictionary data as
a file to the SD card inserted in the Touch Finder.
NA OK OK OK OK OK
Saves all model dictionary data as a file to the SD card
inserted in the Touch Finder.
NA OK OK OK OK OK
Outputs scene data for the Sensor in binary data for-
mat.
NA NA NA NA OK
*
NA
Outputs all scene data in binary data format. NA NA NA NA OK
*
NA
Outputs system data in binary data format. NANANANAOK
*
NA
Outputs all setting data being used by the current Sen-
sor in binary data format.
NA NA NA NA OK
*
NA
Outputs image data stored in the Sensor memory in
binary format.
NA NA NA NA OK
*
NA
Outputs all image data stored in the Sensor memory in
binary format.
NA NA NA NA OK
*
NA
Outputs the calibration data in binary data format.NANANANAOK
*
NA
Outputs the all calibration data in binary data format. NA NA NA NA OK
*
NA
Outputs model dictionary data in binary data format. NA NA NA NA OK
*
NA
Outputs all model dictionary data in binary data format.NANANANAOK
*
NA
