FQ2-S4 User’s Manual
475
Appendices
12
I/O setting
I/O setting
Output
OUT0
to
OUT2
Control
signal
Used to assign output signals to OUT0,
OUT1, and OUT2.
OR (Total judgement) (default), BUSY,
ERROR, READY, RUN, STG
System p. 288
Item
judge-
ment
OR0 (Item0 judgement) to OR31 (Item31
judgement)
Expres-
sion
judge-
ment
Exp.0 judgement to EXP. 31 judgement
OR output You can set the output conditions for the
OR signal and for output signals to which
judgements are assigned.
OK: ON or NG: ON (default) System p. 290
Output mode You can set the output mode for the OR
signal and for output signals to which
judgements are assigned.
One-shot output, Level output (default) System p. 288
Output delay When one-shot output mode is selected,
this parameter sets the delay from when
measurement processing is completed
until when the OR signal turns ON.
0 to 1,000 ms (default: 0 ms) System
Output time When one-shot output mode is selected,
this parameter sets the time that the OR
signal is ON.
1 to 1,000 ms (default: 5 ms) System
BUSY output Specifies when to turn OFF the BUSY
signal after starting measurement pro-
cessing.
Measurement (default), Data logging,
Image logging, or Result display
System p. 291
OUT0 Polarity You can change the polarity of the output
signals that are assigned to OUT0 to
OUT2 (regardless of what signal is
assigned to the output).
Positive (default), Negative System p. 291
OUT1 Polarity Positive (default), Negative System
OUT2 Polarity Positive (default), Negative System
BUSY LED You can change the BUSY indicator to a
RUN indicator.
BUSY (default), RUN System p. 278
Output control You can select the data output method.
(Only when the FQ-SDU1@ is con-
nected.)
None (default), Handshaking, or Sync.
Output
System p. 309
Menu command Description Setting range Data Refer-
