External Reference Parameters
494
FQ2-S4 User’s Manual
120 Mea-
sure-
ment
condi-
tions
Source image Setting/Acqui-
sition
0: Camera image,
1: Previous image
1 --- ---
121 Setting method Setting/Acqui-
sition
0: Filtering OFF, 1: Filtering ON 1 --- ---
122 Image format Setting/Acqui-
sition
0: Binary image,
1: Monochrome image,
2: Color image
0 --- ---
123 Color setting mode Setting/Acqui-
sition
0: RGB common, 1: RGB indi-
vidual
0 --- ---
124 Common color lower
limit
Setting/Acqui-
sition
0 to 255 0 --- ---
125 Common color upper
limit
Setting/Acqui-
sition
0 to 255 255 --- ---
126 R lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
127 R upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
128 G lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
129 G upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
130 B lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
131 B upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
132 Grayscale lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
133 Grayscale upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
