Omron FQ2-S4 User Manual

External Reference Parameters
510
FQ2-S4 User’s Manual
140 Mea-
sure-
ment
condi-
tions
Edge color specifica-
tion 0
Setting/Acqui-
sition
0: No edge color specifica-
tion,
1: Edge color specification
0 --- ---
141 Edge color R0 Setting/Acqui-
sition
0 to 255 255 --- ---
142 Edge color G0 Setting/Acqui-
sition
0 to 255 255 --- ---
143 Edge color B0 Setting/Acqui-
sition
0 to 255 255 --- ---
147 Density change 0 Setting/Acqui-
sition
0: Color IN, 1: Color OUT 0 --- ---
149 Edge level 0 Setting/Acqui-
sition
0 to 100 50 --- ---
150 Noise level 0 Setting/Acqui-
sition
0 to 442 5 --- ---
153 Monochrome density
change 0
Setting/Acqui-
sition
(Monochrome Cameras)
0: Light to Dark, 1: Dark to
Light
0 --- ---
157 Measurement method
0
Setting/Acqui-
sition
(Monochrome Cameras)
0: Projection, 1: Differentia-
tion
0 --- ---
160 Edge color specifica-
tion 0
Setting/Acqui-
sition
0: No edge color specifica-
tion,
1: Edge color specification
0 --- ---
161 Edge color R1 Setting/Acqui-
sition
0 to 255 255 --- ---
162 Edge color G1 Setting/Acqui-
sition
0 to 255 255 --- ---
163 Edge color B1 Setting/Acqui-
sition
0 to 255 255 --- ---
167 Density change 1 Setting/Acqui-
sition
0: Color IN, 1: Color OUT 0 --- ---
169 Edge level 1 Setting/Acqui-
sition
0 to 100 50 --- ---
170 Noise level 1 Setting/Acqui-
sition
0 to 442 5 --- ---
173 Monochrome density
change 1
Setting/Acqui-
sition
(Monochrome Cameras)
0: Light to Dark, 1: Dark to
Light
0 --- ---
177 Measurement method
1
Setting/Acqui-
sition
(Monochrome Cameras)
0: Projection, 1: Differentia-
tion
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
