Omron FQ2-S4 User Manual

External Reference Parameters
534
FQ2-S4 User’s Manual
314 Logging
condi-
tions
Data logging switch for
position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
315 Data logging switch for
position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
316 Data logging switch for
measurement angle
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
317
Data logging switch
for reference position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
318
Data logging switch
for reference position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
319
Data logging switch
for reference angle
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
320
Data logging switch
for NG sub-region
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
321
Data logging switch
for sub-region correla-
tion
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
322
Data logging switch
for sub-region density
deviation
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
323
Data logging switch
for sub-region number
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
324 Data logging switch
for sub-region number (X)
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
325 Data logging switch
for sub-region number (Y)
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
326
Data logging switch
for measurement position
X (sub-region)
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
327
Data logging switch
for measurement position
Y (sub-region)
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
700 Display
settings
Correlation display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
701 Position X display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
702 Position Y display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
703 Measurement angle
display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
704 Density deviation dis-
play
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
705 NG sub-region display Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
800 Mea-
sure-
ment
result
display
Position X display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
801 Position Y display pat-
tern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
802 Measured angle display
pattern
Setting/Acqui-
sition
0: Absolute value, 1: Rela-
tive value
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
