297
Memory Tables
Section 7-3
Reference - In the case described above, both “image/library display” and “screen change-
over” functions are set. The operation when a touch switch is pressed is deter-
mined as follows in accordance with these settings.
Image/library Screen
Touch switch
Image/library
display
Screen
changeover
First time Second time
Not set Not set No effect No effect
Not set Set Screen changeover –
Set Not set Image/library data display No effect
Set Set Image/library data display Screen changeover
- Note that the text will be invisible when the message is pressed, if the color of
message display (color of bit memory table) and the background color in reverse
video of alarm list/history are the same.
[Restrictions]
S The number of bit memory tables can be set as one of the following at the Sup-
port Tool.
- 256 (bit memory table numbers 0 to 255)
- 1000 (bit memory table numbers 0 to 999)
Since the bit memory tables share memory area with the screen data, setting a
large number of bit memory tables reduces the memory area available for
screen data.
[Common Attributes]
Bit memory tables have the following common properties.
Possible Settings
Property
Meaning
Function
None/Switch screen/Alarm
Function of the bit memory table
When “None” is set, nothing will happen even if the host bit to which the
table is allocated comes ON.
Description
Indicates the settings particular to each function.
PC
Any bit address at the host
Address
Host bit to which the bit memory table is allocated
I/O
Up to 16 characters of text
Comment
Comment that describes the contents of a bit memory table
