339
Touch Switches
Section 7-7
[Common Attributes]
The settings common to touch switches are indicated below. Depending on the
function, further settings may be necessary.
S Properties
General
Position Coordinates of the top left corner of the touch switch display
area
Size Width and height of the touch switch display area (dot units)
Label Presence or absence of a character string (label) on the touch
switch
Check mark (character string present)/
No check mark (no character string)
Description Character string on the touch switch
Alphanumerics and symbols, Marks
A maximum of 40 alphanumerics and symbols (or equivalent)
can be set for the label. A mark is recognized as two
characters.
For details on the properties of labels, refer to 7-4-2 “Text (Fixed
Display)” (page 310).
Frame Presence/absence of a frame for the touch switch display
graphic.
Check mark (frame used)/No check mark (no frame)
Shape Shape of the touch switch (display graphic)
⋅
Fixed-shape display frame
No frame/Standard/Shadow/3-Dimension
⋅
Free-shape display frame
Rectangle, Polygon, Circle, Sector
Show ON
State
Whether or not the lamp is displayed in reverse video when a
touch switch is pressed.
Color
Frame Color of the frame (valid only when a check mark is set for
“Frame” above). (Colors other than white and black are featured
with NT31C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
ON Display color when the touch switch is ON (colors other than
white and black are featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
OFF Display color when the touch switch is OFF (colors other than
white and black are featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White/
Transparent
Settings
Function Processing functions executed when touch switches are
pressed
⋅
Notify Bit
⋅
Switch Screen
⋅
Input Key – Control
⋅
Input Key – String
⋅
Input Key – Keyboard
⋅
Copy Setting
⋅
Cursor Move
⋅
Window Move
⋅
Print Screen
To Next Page
