Character String Display
Section 7-9
[Common Attributes]
The relationship between the properties of a character string display and the dis-
played character string is indicated below.
S Properties
General
Position Coordinates of the top left corner of the field in which the character
string is displayed.
Font Type Font for the characters
Standard/Half Height
Scale Scale at which the character string is displayed (“Enlarged dis-
play”, page 369).
11 (Equal), 12 (High), 21 (Wide), 22, 33, 44,
88
Smoothing Whether or not smoothing is used for characters with a scale of
22 or larger (“Smoothing”, page 369).
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Attribute Display mode for the character string (“Display attributes and
drawing result”, page 370).
Standard/Flash/Inverse Flash
Color
Foreground Display color of the text (colors other than black and white featured
with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the text (colors other than black and white fea-
tured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings
Reference
Indirect
Reference
Method for referencing the character string memory table whose
contents are to be displayed (“Direct reference and indirect refer-
ence”, page 370)
Check mark (Indirect Reference)/
No check mark (Direct Reference)
Table Entry Numeral memory table number referenced for display (“Direct
reference and indirect reference”, page 370)
 When “Direct Reference” is specified:
Table number of the numeral memory table in which the
character string to be displayed is stored.
 When “Indirect Reference” is specified:
Table number of the numeral memory table in which the
number of the character string memory table whose contents
are to be displayed is stored.
Length Number of displayed characters
1 to 40
Background color
ABCDE
Position
Foreground color
