386
Graphs
Section 7-10
[Common Attributes]
The relationship between the properties of a broken line graph and the display re-
sults is indicated below.
S Properties
General (properties of the frame)
Position Coordinates of the top left corner of the graph area.
Size Width and height of the area in which the broken line graph is
displayed (dot units)
Width: 2 to 320 Height: 2 to 240
Frame Whether or not a frame is displayed for the graph area
Check mark (frame displayed)/
No check mark (frame not displayed)
Display Sign Whether or not a negative area is displayed.
Check mark (displayed)/No check mark (not displayed)
Direction Direction in which numeral memory table contents are displayed
in the broken line graph (smaller number → larger numbers)
(“Direction of broken line graphs”, page 389)
Up/Down/Left/Right
Color
Frame Display color of the frame (colors other than black and white fea-
tured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
+ Range Display color of the positive range (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
− Range Display color of the negative range (colors other than black and
white featured with NT31C only) (effective only when a check
mark is set for “Display Sign”)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings (properties of each broken line)
Start Table
Entry
*1
First numeral memory table number of the numeral memory tables
used to display the broken line.
Range: 0 to 1998
No. of points
*1
Number of vertices in the broken line display (one memory table
is used for each vertex)
Range: 2 to 320
Interval Type Interval between numeral memory tables in the broken line.
Even/Uneven (cannot resize) (0 to size in the broken line
graph “Direction” − 1)
Line
Color Display color of the broken line (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Style Line type used for the broken line graph
Solid line:
Broken line:
1-dot chain line:
2-dot chain line:
