Graphs
Section 7-10
Settings (properties of each line)
0%
*1
(Specify 0% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number checked to find the 0% value for
percentage calculations (effective only when a check mark is set
for “Display %”)
 Designate the number of the numeral memory table that
stores the 0% value.
Range: 0 to 1999
Value Checked to find the 0% value for percentage calculations
(effective only when a check mark is set for “Display %”)
 Designate the 0% value (default: 0)
Range: −2147483648 to 2147483647
−100%
*1
(Specify -100% value using either of “Table Entry” or “Value”.)
Table Entry Numeral memory table number checked to find the −100% value
for percentage calculations (effective only when a check mark is
set for “Display %”)
 Designate the number of the numeral memory table that
stores the −100% value.
Range: 0 to 1999
Value Checked to find the −100% value for percentage calculations
(effective only when a check mark is set for “Display %”)
 Designate the −100% value (default: −100)
Range: −2147483648 to 2147483647
Logging
Data Logging
Whether or not the logging function is used (“Data logging
function and background function”, page 400)
Check mark (logging function used)/
No check mark (logging function not used)
Background
*2
Whether or not the background function is used (“Data logging
function and background function”, page 400)
Check mark (background function used)/
No check mark (background function not used)
Forward
*2
Presence/absence of a touch switch to proceed to the next
page
Check mark (touch switch set)/
No check mark (touch switch not set)
Rewind
*2
Presence/absence of a touch switch to return to the previous
page
Check mark (touch switch set)/
No check mark (touch switch not set)
Clear Log
*2
Presence/absence of a touch switch to clear the logging data
Check mark (touch switch set)/
No check mark (touch switch not set)
