419
Inputting Numeric Values
Section 7-12
[Common Attributes]
The relationship between the properties of a numeral setting input field and the
numeric values input and displayed is indicated below.
S Properties
General
Position Coordinates of the top left corner of the numeral setting
input field
Font Type Font for the numerals
Standard/Half Height/Double Width
Scale Scale at which the numeric value is displayed (“Enlarged
display”, page 359)
1
×
1 (Equal), 1
×
2 (High), 2
×
1(Wide),2
×
2, 3
×
3, 4
×
4,
8
×
8
Smoothing Whether or not smoothing is used for numerals with a scale
of 2
×
2 or larger (“Smoothing”, page 359)
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Attribute Display mode for the numerals (“Display attributes and
drawing result”, page 359)
Standard/Flash/Inverse Flash
Color
Foreground Display color of the numerals (colors other than black and
white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the numerals (colors other than black
and white featured with NT31C only)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
