Omron NT31 User Manual

429
Inputting Numeric Values
Section 7-12
<Conversion depending on “Display Type”>
The data is converted for storage in a numeral memory table as follows depend-
ing on the setting for “Display Type” (decimal/hexadecimal) and “Display Sign”
(whether or not negative values are indicated.).
- Decimal:
The numeric value input in decimal is converted to signed binary data and
stored in the numeral memory table.
- Hexadecimal:
The numeric value input in hexadecimal is stored in the numeral memory table
without alteration.
Reference:
Numeral memory tables store numeric values as signed binary data.
<Input range and conversion example>
The permissible input ranges depending on the settings made for “Display Type”
and “Display Sign” are indicated in the example below.
Display Type Sign Permissible Input Range
D
e
c
i
m
a
l
Unsigned 0 to 2147483647
Decimal
Signed
$
2147483648 to 2147483647
Hexadecimal – 0 to FFFFFFFF
H
