9-3-8 Numeral memory table write command
(Sent from host to PT)
Command
[Format]
Data of 1 word
Data of 1 word
m
1B 57
[ESC] W t3 t4
4E
Nt1 (l1) (l2)t2
2C 0D
d11 d1m
,
dn1
dnm
(s1) (s2) [CR]
** ** ** ** ** ** **
** ** ** ** ** **
m : Check sum present/absent (1 BCD digit)
0 : Absent
1 : Present
8 : Absent (only 1 table written)
9 : Present (only 1 table written)
t
1
to t
4
: First numeral memory number written to (4 BCD digits)
0000 to 1999 (excluding 0247 to 0253)
l
1
,l
2
: Number of written tables (2 BCD digits)
01 to 20:1 to 20 tables
When m is 8 or 9, omit this setting.
d1
1
to d1
m
, ..., dn
1
to dn
m
:
Contents of the written numeral memory tables (1 to 8
hexadecimal digits)
0 to FFFFFFFF
H
It is possible to omit initial zeroes so that there are less than 8
digits.
s
1
,s
2
: Check sum (2 hexadecimal digits)
When m is 0 or 8, omit this setting.
Reference:
The maximum number which can be specified for numeral memory table depends
on the setting for numbers of numeral table entries (512/1000/2000) made at the
Support Tool.
