Commands/Responses
Section 9-3
Response
Only if “Yes” is set for the “Response” memory switch, the response indicated be-
low is returned on normal completion.
[Format]
1B 57
[ESC] [CR]W
4630 31 0D4D
M
30
0 0 s1 s2
s
1
,s
2
: Check sum (2 hexadecimal digits)
This is always added (fixed as “1FH”).
[Function]
S Writesthe data of the specified number of wordsstarting from the specifiedword
in the PT memory.
S The result after executing the specified operation (write attribute) on the present
contents of the PT memory and the written data is written is as follows.
S A maximum of 50 words can be written at one time.
The write attribute specified by a command executes the following operation on
the present data of the PT memory and the written data and writes the result.
S SET attribute : Specified data is written as it is regardless of the present
data of PT.
S AND attribute : The result after executing the AND operation on the
present data of the PT and the written data is written.
S OR attribute : Theresult after executing the OR operation on the present
data of the PT and the written data is written.
S XOR attribute : The result after executing the XOR operation on the
present data of the PT and the written data is written.
Example:
Write attribute
Written data Present data of the PT memory Result
SET attribute 1234
H
3456
H
1234
H
AND attribute 1234
H
3456
H
1014
H
OR attribute 1234
H
3456
H
3676
H
XOR attribute 1234
H
3456
H
2662
H
