637
Inspection and Cleaning
Section 11-4
S Points inspected
Inspect the following points to determine if there is any divergence from the
stated criteria. If there is, either improve the surrounding environment so that
the values fall within the stated range, or adjust the NT31/NT31C, for example by
re-tightening screws.
Point Inspected Inspection Details Criterion
Inspection
Instrument
Power supply
voltage
Fluctuation in power supply terminal
voltage
Permissible voltage fluctuation range
(24 VDC −15% to +10%)
Tester
Ambient
environmental
Ambient temperature (temperature in the
operation panel)
0 to 50_C Thermometer
conditions
Ambient humidity (humidity in the
operation panel)
35% to 85% RH Hygrometer
Presence/absence of dust Dust must not be settled Visual inspection
Mounting Looseness of mounting brackets, etc. To be no looseness Philips screwdriver
conditions
Connector connections of connecting
cable
To be fully inserted and locked, with no
looseness
Philips screwdriver
Looseness of screws in external wiring To be no looseness Philips screwdriver
Conditions of external connecting cables Faults such as incipient disconnection Visual inspection
Components
with limited
lives
Brightness of the backlight Must be sufficiently bright.
Backlight life:
Brightness is halved after about 25,000
hours in use at medium brightness, or
about 10,000 hours in use at high
brightness.
Visual inspection
Note - Do not disassemble for repairs or modification.
- The disposal of the unit (including batteries to be disposed and backlight) may be
regulated by national or local authorities. Dispose of them in accordance with
the laws and regulations of the relevant country and local authority.
Reference: Desire on replacing the NT31/NT31C
When replacing the NT31/NT31C after discovering a fault during inspections,
note the following points:
- Be sure to switch the power OFF before starting replacement.
- After replacement, check that the new NT31/NT31C is not subject to the same
error.
- If a faulty unit is returned for repairs, write as detailed a description of the fault as
possible and send this description together with the unit to the OMRON address
indicated on the back cover of this book.
To Next Page
