4 - 33
4 Installation and Wiring
NX-series Digital I/O Unit User’s Manual (W521)
4-3 Wiring the Terminals
4
4-3-2 Wiring to M3 Screw Terminal Block
1 Release the lock of the terminal block.
(1) Pull the terminal block cover forward to open the cover.
(2) Pull the terminal block lever downward.
Support the NX Unit firmly while performing the operation of the terminal block lever.
2 Pull out the terminal block straight forward to remove.
Removing a Terminal Block
Terminal block cover Terminal block lever
(1) (2)
