9 Troubleshooting

9 - 2

NX-series Digital I/O Unit User’s Manual (W521)

9-1 How to Check for Errors

Use one of the following error checking methods.

• Checking the indicators

• Troubleshooting with the Support Software

Refer to the user’s manual for the CPU Unit or Communications Coupler Unit that the NX Units are

connected to for information on checking errors with the troubleshooting functions of the Support

Software.
