Appendices
A - 164
NX-series Digital I/O Unit User’s Manual (W521)
A-9 Displaying the Edit Unit Operation
Settings Tab Page
This section describes how to display the Edit Unit Operation Settings Tab Page that is used to create
Unit operation settings on the Sysmac Studio for the NX Units connected to the CPU Unit.
You can use the methods described below to display the Edit Unit Operation Settings Tab Page on the
CPU and Expansion Racks Tab Page on the Sysmac Studio.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for the method of displaying
the CPU and Expansion Racks Tab Page.
z Method 1
Double-click the NX Unit to set.
z Method 2
Right-click the NX Unit and select Edit Unit Operation Settings from the menu.
A-9-1 Connection to the CPU Unit
