• In this manual, “download” refers to transferring data from the Support Software to a physical device
and “upload” refers to transferring data from a physical device to the Support Software.
• In this manual, the directions in relation to the Units are given in the following figure, which shows
upright installation.
• This user's manual refers to the NY-series IPC Machine Controller Industrial Panel PCs and Indus-
trial Box PCs as simply Industrial PCs or as NY-series Industrial PCs.
• This user's manual refers to the built-in EtherCAT port on an NJ/NX-series Controller or NY-series
Industrial PC as simple a built-in EtherCAT port.
• This user's manual may omit manual names and manual numbers in places that refer to the user's
manuals for CPU Units and Industrial PCs. The following table gives some examples. When neces-
sary, refer to Related Manuals on page 27 to determine the appropriate manual based on the com-
mon text for the omitted contents.
Examples:
• This user’s manual may omit manual names and manual numbers in places that refer to the user's
manuals for Communications Coupler Units. If you will use a Communications Coupler Unit, refer to
Related Manuals on page 27 to identify the manual for your Unit.
Precaution on Terminology
Manual name Omitted contents Common text
NJ/NX-series CPU Unit Software User's
Manual
Software user's manual for the con-
nected CPU Unit or Industrial PC
Software User's Manual
NY-series
IPC Machine Controller Industrial Panel PC
/ Industrial Box PC
Software User’s Manual
NJ/NX-series CPU Unit Built-in EtherCAT®
Port User's Manual
User's manual for built-in EtherCAT
port on the connected CPU Unit or
Industrial PC
Built-in EtherCAT port
NY-series
IPC Machine Controller Industrial Panel PC
/ Industrial Box PC
Built-in EtherCAT® Port
User’s Manual
