Omron NX-ID - A-2 Dimensions; A-2-1 Screwless Clamping Terminal Block Type

Appendices
A - 96
NX-series Digital I/O Unit User’s Manual (W521)
A-2 Dimensions
*1. The dimension is 1.35 mm for Units with lot numbers through December 2014.
A-2-1 Screwless Clamping Terminal Block Type
12 mm Width
24 mm Width
80.1
71
104.5
100
14.1
65.2
12.0
(Unit: mm)
1.5 1.5
0.55
*1
26.1
24.0
C D
C
D
(Unit: mm)
80.1
71
104.5
100
65.2
1.5 1.5
0.55
