8-2 Specifications of I/O Data
8
8-2-1 Allocable I/O Data
8-2 Specifications of I/O Data
This section describes I/O data for the Digital Mixed I/O Units.
This section describes the allocable I/O data in the Digital Mixed I/O Units.
An I/O entry mapping is assigned to the I/O allocation settings for the Digital Mixed I/O Units.
A specific I/O entry is assigned to the I/O entry mapping for each NX Unit model. These allocations are
fixed, so you cannot add others or change them.
An I/O entry means the I/O data described in this section. An I/O entry mapping means a collection of
I/O entries.
To assign the I/O allocation information of the NX Unit or Slave Terminal to an NJ/NX-series CPU Unit
or NY-series Industrial PC, use the I/O ports for the allocated I/O data.
However, for Slave Terminals, I/O ports may not be used depending on the type of communications
master or Communications Coupler Unit.
Refer to the user’s manual for the connected Communications Coupler Unit for details on how to use
I/O data for Slave Terminals.
z Thirty-two-point Mixed I/O Units
Input section
8-2-1 Allocable I/O Data
NX Units in Free-Run Refreshing or Synchronous I/O Refreshing
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Input Bit 16 bits The input values for 16
bits.
The following 16 BOOL
data are included.
WORD 0000 hex Input Bit 16
bits
6002 hex 01 hex
Input Bit 00 The input value for input
bit 00.
BOOL FALSE Input Bit 00
Input Bit 01 The input value for input
bit 01.
BOOL FALSE Input Bit 01
•
•
•
Input Bit 15 The input value for input
bit 15.
BOOL FALSE Input Bit 15
