4 Installation and Wiring
4 - 38
NX-series Digital I/O Unit User’s Manual (W521)
3 Assemble the connector (purchased separately).
4 Mount the connector on the Digital I/O Unit and fix it in place with lock screws.
Tighten the connector lock screws to a torque of 0.2
•m.
Nuts (3)
Socket
Connector cover
Small screws (3)
Nuts (2)
Cable bracket
Connector
lock screws
Small screws (2)
Connector
Connector
Digital I/O Unit
Digital I/O Unit
Connector
lock screws
