4 - 51
4 Installation and Wiring
NX-series Digital I/O Unit User’s Manual (W521)
4-4 Wiring Examples
4
4-4-1 Wiring the Input Units
z Contact Output
z AC Switching
Precautions for Safe Use
If you use reed switches for the input contacts for AC Input Units, use switches with an allow-
able current of 1 A or greater. If the capacity of the reed switches is too low, inrush current may
fuse the contacts.
Wiring to the AC Input Units
C
IN
AC Input Unit
C
IN
AC Input Unit
Proximity
switch
main circuit
