7 Digital Output Units
NX-series Digital I/O Unit User’s Manual (W521)
7-2 Specifications of I/O Data
7
7-2-1 Allocable I/O Data
z Sixteen-point Output Units
z Thirty-two-point Output Units
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Output Bit 16 bits The output values for 16
bits.
The following 16 BOOL
data are included.
WORD 0000 hex Output Bit 16
bits
7002 hex 01 hex
Output Bit 00 The output set value for
output bit 00.
BOOL FALSE Output Bit 00
Output Bit 01 The output set value for
output bit 01.
BOOL FALSE Output Bit 01
•
•
•
Output Bit 15 The output set value for
output bit 15.
BOOL FALSE Output Bit 15
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Output Bit 32 bits The output values for 32
bits.
The following 32 BOOL
data are included.
DWORD 00000000
hex
Output Bit 32
bits
7003 hex 01 hex
Output Bit 00 The output set value for
output bit 00.
BOOL FALSE Output Bit 00
Output Bit 01 The output set value for
output bit 01.
BOOL FALSE Output Bit 01
•
•
•
Output Bit 31 The output set value for
output bit 31.
BOOL FALSE Output Bit 31
