7 - 15
7 Digital Output Units
NX-series Digital I/O Unit User’s Manual (W521)
7-4 Function
7
7-4-2 Load Rejection Output Setting
This section describes how to configure settings with the Sysmac Studio.
When you are using Support Software other than the Sysmac Studio, in the Edit Unit Operation Set-
tings Tab Page, set the parameters described in the procedure and transfer the settings to the target
NX Unit.
For details on how to display the Edit Unit Operation Settings Tab Page and to transfer settings to an
NX Unit with Support Software other than the Sysmac Studio, refer to the operation manual for the Sup-
port Software that you are using.
1 Display the Edit Unit Operation Settings Tab Page.
For the display methods, refer to A-9 Displaying the Edit Unit Operation Settings Tab Page on
page A-164.
2 Make the following settings according to the type of NX Unit you want to set.
Two-point or Four-point Output Unit (Data type: BOOL)
Select False (OFF) or True (Hold the present value) from the list of Load Rejection Output
Setting for which the output bit you want to set.
Eight-point, Sixteen-point, and Thirty-two-point Output Units
Enter a set value in the Value text box. The data type of the set values and the range of the
values that you can set vary depending on the number of output points.
Setting Method
Number of output points Data type Set value
8 points USINT 0 to 255
16 points UINT 0 to 65535
32 points UDINT 0 to 4294967295
To Next Page
