Precautions for Safe Use

NX-series Digital I/O Unit User’s Manual (W521)

• When you replace a Unit, start operation only after you transfer the settings and variables that are

required for operation to the new Unit.

• Dispose of the product according to local ordinances as they apply.

Unit Replacement

Disposal
