A - 13
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-1 Data Sheet
A
A-1-2 Digital Input Units
Unit name
DC Input Unit
Model
NX-ID3344
Number of points
4 points
External connection
terminals
Screwless clamping terminal block (12 ter-
minals)
I/O refreshing method
Input refreshing with input changed time
Indicators
TS indicator, input indicators
Internal I/O common
NPN
Rated input voltage
24 VDC (15 to 28.8 VDC)
Input current
3.5 mA typical (at 24 VDC), rated current
ON voltage/ON current
15 VDC min./3 mA min. (between IOV and
each signal)
OFF voltage/OFF cur-
rent
5 VDC max./1 mA max. (between IOV and
each signal)
ON/OFF response time
100 ns max./100 ns max.
Input filter time
No filter
Dimensions
12 (W) x 100 (H) x 71 (D)
Isolation method
Digital isolator isolation
Insulation resistance
20 MΩ min. between isolated circuits (at
100 VDC)
Dielectric strength
510 VAC between isolated circuits for 1
minute at a leakage current of 5 mA max.
I/O power supply
method
Supply from the NX bus
Current capacity of I/O
power supply terminal
IOV: 0.1 A/terminal max., IOG
:
0.1 A/termi-
nal max.
NX Unit power con-
sumption
• Connected to a CPU Unit
0.90 W max.
• Connected to a Communications Cou-
pler Unit
0.50 W max.
Current consumption
from I/O power supply
30 mA max.
Weight
65 g max.
Circuit layout
Installation orienta-
tion and restrictions
Installation orientation:
• Connected to a CPU Unit
Possible in upright installation.
• Connected to a Communications Coupler Unit
Possible in 6 orientations.
Restrictions: No restrictions
Terminal connection
diagram
Disconnec-
tion/Short-circuit
detection
Not supported. Protective function Not supported.
IOV0 to 3
IN0 to IN3
IOG0 to 3
Terminal block
Internal circuits
Isolation circuit
Current control
circuit
Power
supply
NX bus
connector
(left)
I/O power supply +
I/O power supply −
I/O power supply +
I/O power supply −
NX bus
connector
(right)
Two-wire
sensor
Three-wire
sensor
24 VDC
Additional I/O
Power Supply Unit
DC Input Unit
NX-ID3344
IOV
IOG
IOV
IOG
IOV
IOG
IOV
IOG
IN0
IOG0
IOV2
IOV0
A1 B1
A8 B8
IN2
IOG3
IN1
IOG1
IOV3
IOV1
IN3
IOG3
A1 B1
A8 B8
To Next Page
