A - 37

Appendices

NX-series Digital I/O Unit User’s Manual (W521)

A-1 Data Sheet

A-1-2 Digital Input Units

Installation orienta-

tion and restrictions

Installation orientation:

• Connected to a CPU Unit

Possible in upright installation.

• Connected to a Communications Coupler Unit

Possible in 6 orientations.

Restrictions: No restrictions

Terminal connection

diagram

Disconnection/

Short-circuit detection

Not supported. Protective function Not supported.

A1 B1

A8 B8

AC Input Unit

NX-IA3117

200 to 240 VAC

IN0

IN1

IN2

IN3
