A - 69
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-1 Data Sheet
A
A-1-3 Digital Output Units
Terminal connection
diagram
Disconnec-
tion/Short-circuit
detection
Not supported.
Protective function With load short-circuit protection.
1
5
9
3
7
11
15
17
19
13
COM (+V)
OUT15
OUT13
0V
OUT14
OUT12
OUT10
OUT09
OUT08
OUT11
2
6
10
4
8
12
16
18
20
14
24 VDC
COM (+V)
OUT07
OUT05
0V
OUT06
OUT04
OUT02
OUT01
OUT00
OUT03
L L
L L
L L
L L
L L
L L
L L
L L
Connector
pin
Signal
name
Signal
name
• Be sure to wire both pins 1 and 2 (COM (+V)).
• Be sure to wire both pins 3 and 4 (0V).
