A - 79

Appendices

NX-series Digital I/O Unit User’s Manual (W521)

A-1 Data Sheet

A-1-3 Digital Output Units

Terminal connection

diagram

Disconnec-

tion/Short-circuit

detection

Not supported.

Protective function Not supported.

*1. Electrical service life will vary depending on the current value. Refer to Relay Service Life on page 7-20 for details.

Load

NO0

A1 B1

A8 B8

NC0

NC1NO1

C1 C1

Relay Output

Unit

NX-OC2733

Load
