Appendices
A - 142
NX-series Digital I/O Unit User’s Manual (W521)
*1. The default value and data range for Number of Entries are as follows.
*2. The meaning of the set values for Input Bit Mode Setting is as follows.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5006 --- Time Stamp (Mode Set-
ting)
--- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Input Bit 00 Mode Setting FALSE TRUE or
FALSE
*2
--- BOOL RW Not
pos-
sible
Y
02 Input Bit 01 Mode Setting FALSE --- BOOL RW Not
pos-
sible
Y
03 Input Bit 02 Mode Setting FALSE --- BOOL RW Not
pos-
sible
Y
04 Input Bit 03 Mode Setting FALSE --- BOOL RW Not
pos-
sible
Y
NX Units Default value Data range
NX-ID3344/ID3444 4 4 (fixed)
Other models 0 0 (fixed)
Set value Meaning
FALSE Continuous (Last changed time)
TRUE One-shot (First changed time)
To Next Page
