Appendices
A - 150
NX-series Digital I/O Unit User’s Manual (W521)
*1. The default value and data range for Number of Entries are as follows.
*2. The detailed data and meaning of the set values for Load Rejection Output for Output Bit (16 bits) are as follows.
Bit 0: Load Rejection Output for Output Bit 00
Bit 1: Load Rejection Output for Output Bit 01
·
·
·
Bit 15: Load Rejection Output for Output Bit 15
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5012 --- Load Rejection Word Set-
ting
--- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Load Rejection Output for
Output Bit (16 bits)
0000 hex 0000 to FFFF
hex
*2
--- WORD RW Not
pos-
sible
Y
NX Units Default value Data range
NX-OD5121/OD5121-1/OD5121-5/OD5256/
OD5256-1/OD5256-5
11 (fixed)
Other models 0 0 (fixed)
Set value Meaning
0OFF
1 Hold the present value.
