3 Part Names and Functions
3 - 6
NX-series Digital I/O Unit User’s Manual (W521)
z Applicable Terminal Blocks for Each Unit Model
The following indicates the terminal blocks that are applicable to each Unit.
Precautions for Correct Use
You can mount either NX-TB1 or NX-TB2 Terminal Blocks to the Units that the cur-
rent capacity specification of the terminals is 4 A or less.
However, even if you mount the NX-TB2 Terminal Block, the current specification does
not change because the current capacity specification of the terminals on the Units is 4 A or
less.
Refer to A-6 List of Screwless Clamping Terminal Block Models on page A-157 for information
on the models of terminal blocks.
Unit model number
Terminal block
Model
Number of
terminals
Ground terminal
mark
Current capacity
NX-ID3 NX-TBA121 12 Not provided 4 A
NX-TBA122 10 A
NX-ID4 NX-TBA161 16 4 A
NX-ID5 NX-TBA162 10 A
NX-IA3117 NX-TBA081 8 4 A
NX-OD2 NX-TBA082 10 A
NX-OD3268 NX-TBA162 16 10 A
NX-OD3
(any model other than
NX-OD3268)
NX-TBA121 12 4 A
NX-TBA122 10 A
NX-OD4 NX-TBA161 16 4 A
NX-OD5 NX-TBA162 10 A
NX-OC2 NX-TBA081 8 4 A
NX-TBA082 10 A
NX-OC4633 NX-TBA082 8 10 A
NX-TBB082
