4 - 5
4 Installation and Wiring
NX-series Digital I/O Unit User’s Manual (W521)
4-1 Installing NX Units
4
4-1-2 Attaching Markers
z Installation Method
Insert the protrusions on the markers into the marker attachment locations.
z Commercially Available Markers
Commercially available markers are made of plastic and can be printed on with a special printer.
To use commercially available markers, purchase the following products.
The markers made by OMRON cannot be printed on with commercially available special printers.
Product name
Model number
Manufactured by Phoenix Contact Manufactured by Weidmuller
Markers UC1-TMF8 DEK 5/8
Special marker printer UM EN BLUEMARK X1 PrintJet PRO
Marker attachment
location
Marker
Screwless clamping
terminal block
NX Unit
M3 screw
terminal block
Marker attachment
location
Marker Marker
Terminal
block cover
Marker attachment
location
To Next Page
