This section describes how to connect and remove wires.
z Terminal Block Parts and Names
z Required Tools
Use a flat-blade screwdriver to connect and remove wires.
Use the following flat-blade screwdriver.
Recommended screwdriver
Connecting/Removing Wires
Model Manufacturer
SZF 0-0,4×2,5 Phoenix Contact
Terminal hole
Release hole
2.5 mm0.4 mm
Front view
8 to 12
°
Side view
2.5-mm dia.
