4 - 21

4 Installation and Wiring

NX-series Digital I/O Unit User’s Manual (W521)

4-3 Wiring the Terminals

4

4-3-1 Wiring to the Screwless Clamping Terminal Block

3 Bundle the wires with a cable tie and secure them to the screwless clamping terminal block.

Secure wires within the range of 30 mm from the screwless clamping terminal block.

30 mm
