Appendices
A - 34
NX-series Data Reference Manual (W525)
Communications Interface Units
*1. If you use a CPU Unit, the serial communications instructions for the CIF Unit are supported by CPU Units
with unit version 1.11 or later. If you do not use serial communications instructions, you can use version
1.10. Refer to the instructions reference manual for the connected CPU Unit or Industrial PC for details on
the serial communications instructions for the CIF Unit.
Load Cell Input Unit
*1. To use task period prioritized refreshing, you must use the NX-ECC203.
IO-Link Master Unit
Temperature Control Units
*1. When connecting with other manufacturer's master, use the EtherCAT Coupler Unit with unit version
Ver.1.5 or later.
NX Units Corresponding unit versions/versions
Model Unit version
EtherCAT Cou-
pler Units
CPU Units or
Industrial PCs
Sysmac Studio
NX-CIF101 Ver.1.0 Ver.1.0
Ver.1.11
*1
Ver.1.15
NX-CIF105
NX-CIF210
NX Units Corresponding unit versions/versions
Model Unit version
EtherCAT Cou-
pler Units
CPU Units or
Industrial PCs
Sysmac Studio
NX-RS1201 Ver.1.0
Ver.1.0
*1
Ver.1.05 Ver.1.16
NX Units Corresponding unit versions/versions
Model Unit version
EtherCAT Cou-
pler Units
CPU Units or
Industrial PCs
Sysmac Studio
NX-ILM400 Ver.1.0 Ver.1.0 Ver.1.12 Ver.1.16
Ver.1.1 Ver.1.20
NX Units Corresponding unit versions/versions
Model Unit version
EtherCAT Cou-
pler Units
CPU Units or
Industrial PCs
Sysmac Studio
NX-TC2405 Ver.1.0
Ver.1.0
*1
Ver.1.05 Ver.1.21
NX-TC2406
NX-TC2407
NX-TC2408
NX-TC3405
NX-TC3406
NX-TC3407
NX-TC3408
To Next Page
